Honeywell

Honeywell Aquatrol® AQ15540B/U Zoning Module, DIP Switch User Interface, 4 Zones, Import

1318890 MFG #: AQ15540B/U
$296.38 / ea
Honeywell Aquatrol® AQ15540B/U Zoning Module, DIP Switch User Interface, 4 Zones, Import
  • Dimensions: 2-1/2 in H x 3-1/2 in W x 4-1/4 in D
  • Number of Zones: 4
  • Wire Size: 2 x 14 AWG
  • Domestic/Import: Import
  • User Interface: DIP Switch

Honeywell Aquatrol® Zoning Module, User Interface: DIP Switch, 4 Zones, 2 x 14 AWG Wire, Wire-Clamp Screw Terminal, 2-1/2 in H x 3-1/2 in W x 4-1/4 in D, Import

QTY
Add to List
  • Features
  • Replacement control modules for AQ2000 panels
  • 5 to 90% RH non-condensing operating humidity
  • 24 VAC class II (input on control and zoning modules) R-C input
  • Replacement boiler control module for AQ25542
  • Zone pumps or 2-wire valves zoning devices controlled
  • B-B communication bus terminals: low voltage, Class II, 2-wire polarity-insensitive, digital communicating link to other control or zoning modules
  • Zone module thermostat input: low voltage, Class II, 2-wire polarity-insensitive, digital communicating with power link to AQ1000 series thermostat
  • 120/250 VAC, 5 A, 1/3 hp zone output contact rating
  • Wire-clamp screw terminals, maximum 2 x 14 AWG each on line voltage terminals electrical connections
  • 32 to 130 deg F panel temperature
  • AQ1000 series 2-wire communicating thermostats and most digital thermostats thermostat compatibility
  • Standard/Approvals: CSA C/US Certified to CSA and UL Standards, File #LR76030
