WATTS®

WATTS® 0122615 LF007 Double Check Valve Assembly, 3 in Nominal, Resilient Seated Gate Valve, Cast Iron Body, Domestic

1125716 MFG #: 0122615
$8,829.00 / ea
WATTS® 0122615 LF007 Double Check Valve Assembly, 3 in Nominal, Resilient Seated Gate Valve, Cast Iron Body, Domestic
  • Ball Valve/Gate Valve type: Resilient Seated Gate Valve
  • Body Material: Cast Iron
  • Dimensions: 33-1/8 in L
  • Domestic/Import: Domestic
  • Finish: Fused Epoxy Coated
  • Nominal Size: 3
  • Pressure Rating: 175
  • Series: LF007-NRS
  • Temperature Rating: 33 to 110

WATTS®, 0122615, Double Check Valve Assembly, Series: LF007, 3 in Nominal, 175 psi Pressure, 33 to 110 deg F, Resilient Seated Gate Valve Ball Valve/Gate Valve, Cast Iron Body, Fused Epoxy Coated, 33-1/8 in L Dimensions, Domestic

Series LF007 Double Check Valve Assemblies shall be installed at referenced cross-connections to prevent the backflow of polluted water into the potable water supply. Only those cross-connections identified by local inspection authorities as non-health hazard shall be allowed the use of an approved double check valve assembly. The LF007 features Lead Free construction to comply with Lead Free installation requirements. Check with local authority having jurisdiction regarding vertical orientation, frequency of testing or other installation requirements. The valve shall meet the requirements of ASSE Std. 1015 and AWWA Std. C510. Approved by the Foundation for Cross Connection Control and Hydraulic Research at the University of Southern California.

QTY
Add to List
  • Features
  • Utilize advanced ArmorTek coating technology to resist corrosion of internal
  • The valve body shall utilize a coating system with built in electrochemical corrosion inhibitor and microbial inhibitor
  • Compact design
  • No special tools required for servicing
  • Ease of maintenance only one cover
  • Replaceable seat and discs
  • Modular design
  • Low pressure drop
  • Top mounted resilient seated test cocks
  • Non-rising stem resilient seated gate valve
  • Standard/Approvals: ASSE 1015|AWWA C510|CSA B64.5|IAPMO PS31|NSF Approved|UPC Listed | PROP65: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm.
  • INCLUDES: (2) Resilient Seated Isolation Valves and (4) Test Cocks
  • WARRANTY: 1 year Limited
