Oatey® MODA™ 37683 1-Valve Supply Box System Without Hammer, For Use With Ice Maker, Brass PEX Connection, PVC

1357950 MFG #: 37683
$36.24 / ea
Oatey® MODA™ 37683 1-Valve Supply Box System Without Hammer, For Use With Ice Maker, Brass PEX Connection, PVC
  • Dimensions: 8 in W x 3.38 in D x 4.85 in H
  • Material: PVC
  • Specifications: Brass PEX Connection
  • Suitable For Use With: Ice Maker

Oatey® MODA™ 1-Valve Supply Box System, For Use With: Ice Maker, Brass PEX Connection, PVC, 8 in W x 3.38 in D x 4.85 in H

MODA™ Supply Box System is designed to meet the needs of plumbing contractors for washing machine, ice maker, lavatory, toilet, dishwasher and SureVent®Air Admittance Valve applications. A universal single box platform provides maximum versatility, installation simplicity and rugged reliability. MODA™ Supply Box System is the ultimate solution for speed and flexibility.

QTY
Add to List
  • Features
  • Videos
  • Using a single box platform provides significant convenience to installers
  • One universal faceplate is compatible with all box types
  • All boxes can snap to one another and common brackets can be used on any MODA™ supply box
  • Unique interlocking wing flanges accommodate on-stud, straddle-stud and three-box installations
  • Advanced snap-lock design allows assembly and disassembly with equal ease, for quicker installation and easy repositioning on the job
  • Separate valve and drain boxes allow paired or split boxes between walls or stud bays to prevent supply/drain crossovers
  • Dual box design provides ideal options for stacked washer/dryers and space-limited laundry rooms
  • Plumber-preferred, quarter turn test plug with gasket provided with every drain box
  • This means no knock outs falling into drains and no tools required
  • Oatey® exclusive feature
  • Stands up to the roughest job site abuse and no transition cement needed when solvent welding PVC pipe
  • Two piece valve design makes valve replacement easy to repair, without damaging drywall
  • Valves rated to 150 psi air and 250 psi water
  • Forged brass C46500 no lead ( chrome plated )
  • Stainless steel valve retention clip
  • Standard/Approvals: ASME A112.18.1|CSA B125.1|ASSE 1010/F1960|IAPMO Listed|PS-54|NSF/ANSI 61/372|UPC Listed
  • INCLUDES: (2) 8 in L x 4 in W Side Brackets, Sticker Cover and 6 in W x 1.25 in D x 6.45 in H Faceplate
